Tool / Aparat pentru resetare airbag Audi VW

For Audi-VW Airbag Reseter



Top 2 Reasons to Get for Audi-VW Airbag Reseter

1. Language: English
2. No Need To Connect with PC

Description:

1. for Audi-VW Airbag Reseter works without additional computer and trough car OBD II connector can erase airbag senzor "crash data" or only fault memory.
Very simple user instruction: connect this tool for Audi/VW car OBD II connector. Right red buton is for airbag "crash data" erase. Push this buton once and wait: yellow light start to flash and after 15 second green light inform you that "crash data" is erased. Red light set ON if erasing is not successful.

2.Left yellow buton is for erase airbag "fault memory" or "errors". If airbag warning lamp go OFF and immediately ON, evaluate airbag "error memory" using any for VW-Audi diagnostic equipment and repair.

Suport list:

1. Suport for new Audi airbag sensors(with hc12cpu or CR16 PLCC44 ) 1999-2002 crash data and DTC65535 (Controller Malfunction) erase, such as:4B0959655G, 4B0959655J,4B0959655C, 8L0959655G, 4D0 959 655 J, 8D0 959 655 J , 8D0 959 655 F, 8D0 959 655 M, etc

2. Suport new Airbag senzor (with CR16 80QFP) for VW-Audi (A3, A4, A6, A8 2002-2005, Touareg) crash data and DTC65535 (Controller Malfunction) erase, such as 4B0959655Q ,etc.

3. Suport crash data and fault memory erase:

for AUDI A4, A6, A8 1994-1997: Airbag V for BOSCH : 8A0 959 655 C (for Bosch 0 285 001 038), 8A0 959 655 K (for Bosch 0 285 001 155), 8A0 959 655 K (for Bosch 0 285 001 151) - Crash data erase, Fault erase;
for AUDI A3, A4, A6, A8 1999 : Airbag 7 for BOSCH - 4B0 959 655 C, 4B0 959 655 J, 4D0 959 655 C, 4D0 959 655 H, 8D0 959 655 C, 8D0 959 655 L, 8L0 959 655 F - for all Bosch Airbag 7 - Crash data erase, Fault erase;
for Audi A2, A3, A4, A6, A8 - 1999 : Airbag 8 for BOSCH - Crash data erase, Fault erase (can't erase "Controller Malfunction" for this moment);for VW - Golf III, Passat B4, Sharan - 1J0 909 603 SIEMENS - Crash data erase, Fault erase;
for VW - Golf IV, Passat B5 - 1J0 909 609, 1J0 909 607 - SIEMENS - Crash data erase, Fault erase;
for VW - Golf IV, Passat B5 - 3B0 959 655 B, 8L0 959 655 A - for all BOSCH - Crash data erase, Fault erase;
for VW - Golf IV, Passat B5, Sharan - 6Q0 909 605 A, 6Q0 909 605 B - SIEMENS - Crash data erase, Fault erase;
for VW - Golf IV, Passat B5, Sharan - 1C0 909 605 C, 1C0 909 605 F, 1C0 909 605 H, 6Q0 909 605 C - SIEMENS - Crash data erase, Fault erase;
for VW - Passat B6 - new SIEMENS - Crash data erase, Fault erase.

Package list:

1pc x for Audi-VW Airbag Reseter
1pc x OBDII connector

FAQ:

Q: Customer says when it connect the car, the yellow light is on, few seconds later, fail red light is on, but it can not reset the airbag.
A: In this case, it means it can not do this car.

Q: SR03 can read the chip to clear the fault code?
A: It can not read the fault code and read chip.
